The product has a sensitivity detector and an integrated circuit. It provides automation, convenience, safety and energy-efficiency. It utilizes the infrared energy reflected from human body as control-signal source and it sets off the load at once when one enters the detection field. It can identify day and night automatically. It is easy to install and has a wide usage application.

SPECIFICATION:

Power Source: 220-240V/AC                 Detection Range: 360°

Power Frequency: 50Hz,
                                                              Detection Distance: 6m max(<24???)
Ambient Light: <10-2000LUX (adjustable)
                                                              Working Temperature: -20~+40???
Time Delay: Min.10sec±3sec
                                                              Power Consumption: approx 0.9W
Working Humidity: <93%RH Max.7min±2min
                                                              Power Consumption: approx 0.9W Rated Load: Max.2000W

Installation Height: 2.2-4m 1000W            Detection Moving Speed: 0.6-1.5m/s

FUNCTION:

Can identify day and night automatically: The consumer can adjust working state in different ambient light. It works in daytime and at night when it is adjusted on the “+” position (max). It works in the ambient light less than 10LUX when it is adjusted on the “-” position (min). As for the adjustment pattern, please refer to the testing instructions.


Time-Delay is added continually: When it receives the second induction signals within the first induction, it will restart to time from that moment.
