The product is a new saving-energy switch; it adopts microwave sensor mould with high-frequency electro-magnetic wave (5.8GHz) and integrated circuit. It gathers automatism, convenience, safety, saving-energy and practicality functions. The wide detection field depends on detectors. It works by receiving human motion. When one enters the detection field, it can start the load at once and identify automatically day and night. Its installation is very convenient and its using is very wide. Detection is possible to go through doors, panes of glass or thin walls.

SPECIFICATION:

Voltage: 110-277V/AC                                      Power Frequency: 50/60Hz

Detection Angle: 360°                                      Detection Range: 50%, 100%(choice)

Daylight sensor: 2lux, 10lux, 50lux,                   Detection Distance: 4-10m (radius), adjustable

2000lux (choice)                                                HF System: 5.8GHz CW radar, ISM band

Transmission Power: <0.2mW                           Power Consumption: approx 0.9W

Hold Time: 5s, 30s, 90s, 3min, 5min,                 Detection Motion Speed: 0.6-1.5m/s

10min, 20min, 30min (choice)                           Installing Height: 4-15m

Stand-by Period: 10s, 1min, 5min, 10min,         Rated Load: Max.2000W (220-277V/AC)
