Body Material: Brass
-
Type: Normally Closed (opens when energized)
-
Port Size: 1/2", 3/4", or 1" BSP (internal thread)
-
Operating Voltage: 12V DC / 24V AC / 230V AC (depending on coil variant)
-
Coil Housing: Sealed black plastic, dust- and water-resistant
-
Wiring: 3-core (Live, Neutral, Earth or Control), flying leads
-
Pressure Range: 0.3 – 8 Bar
-
Temperature Range: 0°C to 80°C
-
Ingress Protection: IP65 (ideal for outdoor irrigation use)
-
Mounting Orientation: Vertical preferred for proper operation
-
Flow Control: On/Off based on electrical input
-
Suitable Media: Water, air, non-corrosive liquids
-
Applications:
• Smart irrigation systems
• Water supply automation
• Tank level control
• Garden or greenhouse automation
-
Product Name: Candle Pro Smart WiFi One Switch Controller
Product Code: CO-CSM-SXP-R1
Accessibility: Online & Offline Control
Manual Switch Integration: Yes
Mobile App: Candle Pro
3rd Party Compatibility: Amazon Alexa, Google Home, Smart Things, IFTTT, Apple Siri
Shortcuts
Additional Integration: NFC Based Switching
Voice Assistant: Amazon Alexa, Google Assistant, Apple Siri
Wireless Connectivity: IEEE 802.11 b/g/n, 2.4GHz
No. of Relays: 1
Electrical Ratings: Max. Load 16A, 230V, 50-60Hz AC
Power Monitoring: Yes, provides power usage details
Warranty: 1 Year Standard Warranty
